FK2-VT+5
CLAMPING UNIT
FK2-VT+5
CLAMPING UNIT
Description
SPECIAL MODELSSpecial models include machinable jaw models, additional piece models and models designed for castings. BK2-VT Stainless steel mode is specially designed for use on EDM machines.
Dimension
| MODEL NO | Length(min.) | Length | Length(MAX.) |
|---|---|---|---|
| FK2-VT+5 | 67 | 70 | 75 |
| MODEL NO. | A | B | C | D | E | F | Socket Head Screw DIN 912 |
Pressing force of jaws, kN |
||
| min | optimum | max | ||||||||
| FK2-VT+5 | 67 | 70 | 75 | 56 | 29 | 42 | 5.0 | 3 | M16x 040 | 100 |
| Weight in kg approx. | Hardness of jaws HRC |
|
| 0.550 | 30 -34 |
NOTICE: Except BK2-VT+3 only with flat-jaw, others have falt or serrated jaw.
